ML100S24DC
Magnetic Driver

Diffusion ML100S24DC

Diffusion ML100S24DC is a magnetic low voltage,
24DC dimmable LED driver.

Features

• Nema 3R for Indoor/Outdoor use
• Uses an assortment of dimmers including CFL/LED style
• Built in divider eliminating the need for a box
• Standard 3/8" KO
• Max load rated
• Mini breakers on the line and the low sides

*See dimmer compatibility list*

Specifications

• Input Voltage : 120V 60Hz
• Max Input Current at Full Load : 1A
• Output Voltage Without Load : 27.2 VDC
• Output Voltage : 23.6 VDC
• Max Wattage : 96W
• Max Output Current : 4A
• Efficiency : 85%
• Load Regulation : 0%
• Ripple : 0
• Wattage : 100W

Dimensions

9.19" L x 3.94" W x 1.63" H
233.40mm L x 100.00mm W x 41.40mm H
